MEASURING MASTER MPP-1 Digital Volumetric Dispenser

Product information "MEASURING MASTER MPP-1 Digital Volumetric Dispenser"

Volume Measuring & Plunger Dispensing System; Dispensing Volume 0.00001-0.65 ml; Viscosity Range 1-100,000 mPas; Liquid Material Supply Pressure 0.001-0.500 MPa

Musashi Engineering’s volume measuring type digitally controlled dispenser MEASURING MASTER™ MPP-1 provides precisely constant volume dispensing of fluids with variable or changeable viscosity – for example dispensing various optical adhesives in photonics applications.

This system’s ultra-precise dispensing is available thanks to a volume measuring type, digitally controlled plunger. With its wide range of pump capacity variations, MEASURING MASTER™ MPP-1 allows to pump capacity (fully filled volume) to suit application requirements.

Various customizations are available to suit liquid material specifications. An optional slit nozzle allows even full-surface film dispensing in a single pass.

A broad portfolio of accessories is available for Musashi Engineering’s dispensers, ranging high-precision, high-quality, highly reliable syringes & accessories to unique nozzles and needles that can handle any type of fluid and dispensing requirements as well as other accessories for dispensers.

Key Features:

• Ultra-precision Constant Volume Dispensing of Liquid Material With Varying Viscosity
• Wide Applicable Viscosity Range: 1 to 100,000 mPas
• Storage Capacity for as Many as 400 Channels of Dispensing Conditions Provided by Multi-channel
• Set Dispensing Volume to Suit Capacity and Density
• High Resolution
• High Linearity
• Tool-less Operation: Fluid Replacement Executable Without Any Tool
• Easy Maintenance for Fluid-exposed Part
• Dispensing System: Volume Measuring Type & Plunger Type
• Control System: Microcomputer Digital Control System
• Dispensing Volume Range Standard Type: 0.15 ml
• Dispensing Volume Range B1 Type: 0.15, 0.30 or 0.65 ml
• Minimum Dispensing Volume Setting Value: 0.00001 ml
• Liquid Material Supply Pressure Range: 0.001 to 0.500 MPa
• Applicable Containers: Syringe (10, 20, 30, 50 or 70 ml)
• Channel Number: 400 Channels
• Rated Voltage: 100 to 240 VAC, 50/60 Hz
• Power Consumption: 25 W
• Dimensions Controller Section: Width 300 mm x Depth 250 mm x Height 111 mm (Excluding Protrusion)
• Weight Controller Section: Approx. 4.5 kg
• Dimensions Head Section: Width 25 mm x Depth 86.5 mm x Height 320 mm (Excluding Protrusion):
• Weight Head Section: Approx. 850 g (Not Containing Container and Liquid Material)
• CE Marking Certified, EU RoHS Compliant

Applications

Constant Volume Dispensing of Fluids With Changeable Viscosity; Dispensing Vial Bottles; Potting of Sensor Components; OCR (Dam); Oil Filling With Precise and Constant Volume; Dispensing of Battery Electrolyte; Ink Dispensing; Underfilling
